Comments: (3)

Un nuevo frente marítimo para Palma de Mallorca

Category: ⚐ ES+espacio público+sostenibilidad+urbanismo

En 2018, la ciudad de Palma de Mallorca se propuso reformar su paseo marítimo frente a la zona portuaria, y convocó un concurso abierto para ello. Hoy os contamos algunos detalles sobre nuestra propuesta, que quedó finalista.

El reto consiste, principalmente, convertir lo que ahora es una barrera, un borde, en un nuevo espacio urbano que conecte la ciudad con el puerto. Nosotros proponemos una transición en la forma de entender ese espacio público, desde concebirlo como un “paseo” lineal a verlo como un “frente” marítimo más amplio, un lugar donde la ciudad pueda expandir sus usos actuales y descubrir otros nuevos.

La propuesta es crear un espacio con nuevas cualidades, un eje cívico donde la ciudad pueda ver reflejada su identidad, aportando representatividad y, sobre todo, añadiendo a ese espacio valor de uso para ciudadanos y visitantes. No se trata, por tanto, solamente de un proyecto de pacificación del tráfico y renaturalización, sino de caracterización y activación.

El enfoque general del proyecto se puede desglosar en una serie de criterios o líneas de actuación. Estas líneas se han agrupado en cuatro “frentes” (integrado, ambiental, activo y conectado) entendidos como capas del frente costero que sintetizan las prioridades de la propuesta e ilustran la visión de la ciudad que la sustenta.


continue reading

Comments: (0)

Febres Cordero | A new hybrid building in the historic center of Cuenca

Category: ⚐ EN+architecture+ecosistema urbano+mixed-use building+sustainability

Vista aerea febres

The Febres Cordero building was developed within the scope of CUENCA RED, the urban reactivation strategy for Cuenca, Ecuador. The aim of Cuenca Red was to incorporate activities and programs in the Historic Center in order to create a new network of reactivated public spaces. One of those spaces is Febres Cordero, an emblematic and historical building which had functioned as a school for decades.

This building has great heritage value and has one of the largest courtyards of the entire historic center (3,300 m2). It is located on Gran Colombia Street, right next to the tram line. It is comprised of two main volumes, one of them  with much less quality and architectural interest.

The building was going to stop its activities within a few months of the beginning of the project, as the school was going to be relocated into a new building. Also, the school has been an important node of social and economic activity for years on the area. This large community injects daily activity into the center of Cuenca.

Fachada Exterior Febres Cordero

Activity from the beginning

One key aspect of the project was not only to design a building with new uses and programs, but also to plan the transition process between one moment and the other. We conceived the project from its Phase 0, in order to unleash, through different actions and activities, dynamism and interest in the future of the building and its interior space.

Space is activated from the beginning, dividing the construction into 3 phasesThe project is planned in 3 phases. The first one is really important, consisting of the opening and reactivation of the central courtyard as a public space for events and activities. This phase is esentially low cost, but its implementation will have a strong impact in keeping momentum and activity around the area, and also generating interest and expectations around the building. Subsequently, the reconditioning and construction of the building will be carried out, and finally the climatic conditioning of the new interior square.

In search of new uses

Following our conclusions of the urban analysis, we noted the progressive emptying of housing in the Historic Center of Cuenca. Although the center still continues to be an active space for tourism and commercial activity, the number of residents is decreasing, moving towards the perimeter of the city center.

This is certainly a problem, especially in the afternoon or the evening, when the shops and offices close, and the lack of activity and people in the area becomes more evident. That emptiness generates unfavorable conditions, like sense of insecurity, or an increase in the number of abandoned or underused properties.

FebresCordero_01

Current status of the interior patio of the Febres Cordero School in Cuenca, Ecuador.In this complex context we identified, through a participatory process partly hosted in the school itself, the need of strengthening the resident population living in the center of Cuenca. It was also key to generate conditions for other families to consider attractive and feasible to live there. The inhabitants of the CHC and technicians who participated in the participatory process agree that the building has optimal conditions to become a new “catalyst” of the city. The Febres Cordero building can be reconstructed as a pilot project that will address many of the opportunities and challenges shared with other historic centers in Latin America.

L1069463

Participatory activities carried out with the students of the Febres Cordero School

A hybrid architectural complex

Febres Cordero does not only house a school, but also commercial premises along the ground floor. The project aims to enhance this aspect, creating a hybrid building capable of bringing together different programs, generating a diverse community that serves as a reference for social and economically sustainable urban intervention.

The rehabilitation of the Febres School seeks three main goals, as steps towards the improvement of the Historic Center:

  • Increasing the extension of public spaces in the area
  • Providing diverse housing typologies (including social housing)
  • Generating a new heart of urban activity through the insertion of new facilities.

Hybrid program of the new complex

To achieve this, Febres Cordero comprises 3 components:

  • Rehabilitation of the existing heritage building (4.500 m2) with new apartments, students dormitory, commercial ground floor, common workspaces, rest area and an elevated outdoor public space.
  • Construction of a new building (5.000 m2) on the surface freed by the demolition of the unprotected building. It is mainly residential and will also have a series of additional services and facilities that are of a public nature and therefore accessible to the rest of the inhabitants of the complex.
  • Reconfiguration of the inner courtyard as a new public square for the city (3.300 m2).
ESTRATEGIAS FEBRES

The new building is connected to the heritage building by corridors

A new public square

The courtyard is conceived as a new public square for the city. It recovers the entrances from the 3 adjacent roads and generates an active and attractive, programmable public space. The ground floor will be adapted to reinforce this idea, promoting permeability and the visual connection between the streets and the courtyard.

3-accesos-Febres

New public square, with 3 entrances from the surrounding streets

The proposed square includes two conditions: a flexible space with a mobile grandstand that allows the creation of different configurations for cultural and sport events, and a more natural space, a cuencan garden inspired by the multiple existing green patios that together create a network of vegetation and biodiversity in the historic center.

Respecting heritage

We are aware of the historical value of a building like this. After a careful study of the history, typology, and construction of the building (built around 1900), the intervention was designed to preserve and respect its historical value and at the same time to introduce new structures to diversify the possibilities of use and adapt it to the evolving urban context.

The intervention respects and seeks to value the intrinsic qualities of the building, and also wants to create a dialogue with the most innovative construction techniques.

TOMO 2.pdf

View of the new public space with the mixed-use building connected to the old Febres Cordero School.

Sección Transversal de la Escuela Febres Cordero

Cross section. A relationship between the new mixed building (left), the public square (center), and the heritage building (center and right).

gif_plantasFC

Architectural plans of the refurbished complex.The main strategy consists of concentrating the utilities or technical systems of the apartments in spines perpendicular to the façade line. This way we can  to minimize the impact on the façade and generate cross ventilation in all the rooms. The exterior façade is not altered by any of the interior interventions and will preserve its current structure and image towards.

On the other hand, the roof was in poor condition. Activating the space under the roof with the creation of a new housing ring towards the interior of the patio enabled us to expand the useful surface without impacting the building on its exterior appearance and its relationship with the public road.

Maximum sustainability

In a project as ambitious as Febres Cordero, the most appropriate technical mechanisms must be sought to achieve maximum economic, social and environmental sustainability. The final design and construction systems were devised under the following sustainability criteria: following bioclimatic design principles for better energy efficiency, adopting local materials and construction techniques to improve durability, and considering the economic impact of the construction at a local level.

Estrategia-habitacional-01

Adaptation of housing typologies to the structural modules in the heritage building.

Comportamiento bioclimático Febres Cordero

Basic outline of the bioclimatic behavior.

The rehabilitation of Febres Cordero is also conceived to be financially sustainable, allowing a short-term return of the investment with the sale and lease of housing and commercial premises, and with the generation of new economies in the urban area.

In general, this rehabilitation project, a pilot within the general Cuenca Red plan, will increase the intensity of use, the possibilities of social interaction and the generation of economies that contribute to the long-term sustainability of the historic center.

You can see the full documents of this project in our portfolio.

Comments: (0)

Unveiling the latest images of the Banyan Hub | A project for a new Hybrid Building in West Palm Beach, Florida

Category: ⚐ EN+ecosistema urbano+mixed-use building+sustainability+work in progress


After winning the international competition Shore to Core, commissioned by the West Palm Beach Community Redevelopment Agency (CRA) and organized by the Van Alen Institute in 2017, Ecosistema Urbano is developing several parts of the proposal, among them the visionary Banyan Hub building.

The Banyan Hub project arises from the intuition of the City of West Palm Beach and the CRA to transform the existing Banyan Garage, a car-devoted building from the 70s in the heart of the Downtown, into a new opportunity to activate the city, a hub for dozens of new activities for both residents and visitors.

Ecosistema Urbano has finalized the Schematic Design of the project that has been officially approved by the West Palm Beach City Commission on Oct. 22. The project will be further developed in the next months.

The Banyan Hub in the surrounding context of West Palm Beach.

A hybrid and flexible building open day and night
The Banyan Hub offers in a single building a wide range of different programs, from open and public spaces to reserved and private areas. The wide variety of possibilities that the building brings will have an important impact on the way of living in West Palm Beach Downtown. The programs collaborate with one another, creating a public facilities machine in which each part works separately, but all of them work together to offer the user a superb experience of public-private spaces. The program includes urban plazas, retail and catering, rooftop pavilion, YMCA, business hub, mobility hub, housing, and city support area.
Sustainability and bioclimatic design are key ingredients of the Banyan Hub, that is strongly characterized by its breathing façade, two courtyards, and multiple active and passive climatic devices.

Banyan Hub | A complex program building enveloped by a green permeable skin.

Urban bioclimatic plazas: expanding public space possibilities and multiplying them by 3
The public heart of the Banyan Hub beats on the three public plazas located on different levels:

  • A flexible and permeable plaza at ground level, with an open hall connected to the surrounding streets and to the rear passageway, that integrates retail, catering and several support spaces.

Banyan Hub | Ground Floor Plaza layout.

  • A covered open-air plaza at an intermediate level for temporary events, including spectacular features such as a digital interactive waterfall or a green courtyard, or local programs as the farmers market.

Enjoying urban life at Banyan Elevated Urban Plaza.     .

  • A top terrace, overlooking the lagoon offering a panoramic view of the unique Floridian natural environment and of the whole Downtown. The terrace accommodates a civic pavilion to host civic events (public meetings, projections, performances) as well as private events such as weddings.

Celebrating at the Banyan Hub Rooftop Terrace.

Interconnected public spaces
The three main public spaces will be connected to provide the experience of having a chameleonic journey through different environments. The Downtown is connected to the middle level elevated urban plaza through an exterior escalator that dynamizes the façade on Banyan Blvd., allowing to stop by the retail ring at the first two levels. From the elevated plaza, it will be possible to go up to the terrace using the breathtaking helical ramp around the green courtyard.

Banyan Hub Bioclimatic Design | A green living building.

A building green in the middle
Other uses in the central block of the building are the Business Hub and the YMCA, each of them occupying two levels. Both areas feature the presence of the central green courtyard, an open-air multi-level natural space that gives continuity to the landscaped urban plazas of the building. Moreover, the green courtyard has a relevant passive bioclimatic function as it would help to reduce temperatures by up to 5ºF and regulate ventilation, providing pleasant environmental conditions throughout the year while reducing environmental impact and management and operational costs.

Business Hub | Working at the Banyan Hub in close connection to nature.

A breathing skin
The façade acts as one of the main conditioning systems of the building, filtering the direct sunlight and regulating ventilation. It is formed by an array of individual elements that present a responsive behavior, autonomously sensing the climatic conditions and the needs of the building and changing their configuration. Protected by the external shading, there is a green buffer zone, mainly comprised of a permeable structure holding vegetation and supporting varied activities. This space acts as a second natural filter for light and breeze and contributes to the regulation of the internal temperature through evaporative cooling.

YMCA at Banyan Hub | Exterior running track at 113’ at Banyan YMCA.

YMCA at Banyan Hub | Swimming in the sky at Banyan YMCA.

Living overlooking the lagoon
The upper block of the building is dedicated to housing. The residential units face out to the exterior, enjoying privileged views of the city and the lagoon. A modular system allows for the combination of units of different sizes, ranging from 500 to 1500 sq.ft. Limited living spaces of micro-units are compensated by indoor and outdoor common facilities, specifically conceived to foster the sense of community of residents. Residential units are arranged around a shared courtyard, where vegetation will help to refresh the interior micro-climate, maintaining the appropriate temperature and humidity levels to achieve comfort for users.

Living at Banyan Hub | Outdoor common facilities for residents.

Banyan Hub | Cross section and night elevation in Olive Ave.     .

Making an invisible parking
The Banyan Hub will continue to serve as a municipal garage for the city’s needs, as its functioning is crucial to parking management of West Palm Beach Downtown. However, the parking will be completely upgraded using an Automated Parking System technology. With this system, the required 350 parking spots will occupy only the ⅔ of the volume currently used by the existing Banyan garage. Moreover, as the ambition of the Banyan Hub is to be an active piece of the city that projects its active life towards the surrounding context, a specific solution has been designed to ensure that the uses along the façades reflect the dynamism of the building. The 4 levels of parking are enclosed at the very core of the building, completely hidden from the outside; these are surrounded on 4 sides by two levels of retail and catering connected by a public corridor that gives architectural quality to this space while activates it.

About West Palm Beach Community Redevelopment Agency
Created in 1984 and authorized by Florida’s Community Redevelopment Act of 1969 (F.S. 163, Part III), the West Palm Beach CRA is nationally recognized as one of the most innovative and effective Community Redevelopment Agencies (CRAs) in the country and is setting the standard for redevelopment. The downtown core has gone through a rebirth with substantial private investment including commercial and residential development. Public investment dollars total in the millions with a state-of-the-art library, revitalization of the historic Sunset Lounge, streetscape infrastructure, and an enhanced waterfront. The CRA continues to coordinate with the City and other agencies to market and revitalize the downtown.

Comments: (0)

An Overview to our Latest Projects in Latin America

Category: ⚐ EN+architecture+Centro Histórico Abierto+city+Cuenca Red+ecosistema urbano+Plan CHA+Plan Encarnación Más+sustainability+technologies+urbanism

During the last year we have been busy with several projects and competitions (including the latest Open Shore project for West Palm Beach) which didn’t give us the time to look back and reflect on some of our projects from the last few years.

As maybe some of our readers know, Ecosistema Urbano has been working on several large-scale projects in Latin America since August 2014 when we won a competition to develop the Master Plan of the Historical Center of Asuncion, Paraguay. In 2015, we accomplished another significant project: the participatory process Centro Histórico Abierto for the transformation of the historical center of Distrito Central, capital of Honduras. We also worked on the transformative Cuenca RED project which acted on the Public Space Reactivation Plan of the Historical Center of Cuenca, Ecuador. After the first experience in Paraguay, we had another project in the city of Encarnación, giving origin to the Plan Encarnación Más, composed by an Urban and Territorial Planning and Sustainability Plan.

In these four cases, the urban issues and the peculiar situations that required our intervention were distinct yet shared many common features. More specifically, the enthusiasm and interest shown by the people directly and indirectly involved was apparent throughout all of the projects, but also the opportunities that these experiences have given us as an architecture firm, to test ideas, tools, and methodologies.

CONTEXT

Although they share the same area of origin, each of these cities has developed unique problems and issues. Some of these, such as the ones found in Encarnación, are physical-territorial matters such as the recent loss of the city center because of the controlled rise of the water level in the Yacyretá dam. That event led to the envisioning of a “Sustainable Development Plan” and  “Urban and Territorial Ordering Plan” in order to prepare the city for the future. In the case of Cuenca, the need for a new plan was determined by a series of big changes underway: the definition of a new model of mobility and the progressive emptying of population that afflicts the historical center, World Heritage Site since 1999, and headquarters of most of the commercial, touristic and economic city’s activities. In the case of Asunción and of the capital of Honduras, the project regards the transformation and the regeneration (both physical and social) of their historic centers. The Distrito Central is part of the development framework of the new urban axis “Choluteca River”.

SOCIAL

1 – Participation

The first of the projects’ common keys are connected with the theme of sociability, expressed in the form of participation. The citizens’ involvement, promoted both through a series of organized activities and through online platforms, has been one of the cornerstones of our work in Latin America. We involve citizens because we believe that the citizen is the only force able to achieve a deep and lasting change in the urban environment and so they should not be just a passive receptor of the changes promoted by the city’s institutions. That’s why in some cases, as in that of Asunción with the ASU-LAB, a space was created which could serve as an interface between citizens and institutions: a place for the execution of the city planning but also an open place where each person or group can drive a new regeneration initiative or attend a course.

Organized activities with the citiziens

Organized activities with the citizens

Participatory activities, such as workshops and events, have been geared to address representative members of the city such as children, university students, “active agents”, citizens and institutions. For each of these categories we have developed, project after project, a series of ad hoc initiatives.

Participatory process in Asunción, Encarnación, Cuenca and in Distrito Central

Participatory process in Asunción, Encarnación, Cuenca and in Distrito Central

For the children we created a “toolkit” with which we had them reflect on their perception of the city and with which they could propose their ideal vision for the city. The kit consists of portions of the city map on which they could draw and that, once recomposed, could recreate the overall image.

2 – Urban actions

These activities were followed by a series of urban actions so that the results could be shown tangibly in the city. In the case of Distrito Central, ideas were gathered in a week of workshops with 80 students from the three major universities in the city and have been translated into urban actions like “Las Gradas de la Leona“. The staircases are indispensable spaces in a city with a very distinct topography as Tegucigualpa. But in the city these vertical connections are often perceived as inhospitable, dangerous, and dirty places and therefore they are cut off from any kind of activity. The students’ work was aimed at legitimizing these stairs as a public space through cleanliness,  decor,  lighting, and the organization of a series of activities that achieved resounding success and participation.

Socialization along "Las gradas de la Leona"

Socialization along “Las gradas de la Leona”

In the case of Encarnación, one of the proposals that has distinguished our approach in this project was the inclusion of a series of pilot projects that accompany and translate into concrete proposals within the “Plan de Desarrollo Sustentable” and the “Plan de Ordenamiento”. Among these, one of the most successful pilot projects was the “Proyecto Piloto Bicisienda“, whose purpose is to improve the quality of life of the inhabitants by optimizing the use of alternative mobility and by raising awareness of the value of sports and recreation. Again we have sought the cooperation of citizens by promoting a series of initiatives (such as the construction of bike lanes in the city) in which the citizens could feel protagonistic.

Proyecto Piloto Bicisienda

Proyecto Piloto Bicisienda

3 – Informative events

The disclosure of the participatory process to the citizenship, promoted both online through the project’s platforms and through open exhibitions, is a recurring phase in all four projects. We felt it important and necessary that each phase of the process was documented and could be easily accessible to all so that the citizens could be informed about the progress made in the project. Among these, the most scenic event, realized in Tegucigualpa, Cuenca and Encarnación, was the creation of a ” mosaico ciudadano“, a wall made of post-it notes with written words, phrases, and ideas about the city.

City mosaic in the several projects

City mosaic in the several projects

SUSTAINABILITY

Another theme of our projects in Latin America is sustainable development expressed in various forms: care and attention to the environment, the introduction of an alternative mobility system, the importance of education to the environment as an engine of sustainability, and the development of the project made in collaboration between private initiatives and institutional management. In the case of Cuenca, for example, our intervention was partly required as a consequence of the municipality’s willingness to define a new model of mobility for the historical center of the city consisting of ceasing car traffic in the center and building a new tramway system. This new model of mobility has direct implications for the current urban dynamics, as well as on the public space, as it tries to reduce the vehicular load of the city, giving priority to pedestrians and cyclists. This, and the creation of quality public space, led to strengthen the social, economic, and cultural role of the city’s historical center making it more pleasant for residents and locals. Our aim is to activate a historical center that promotes social, economic, and environmental development, as well as a more livable, habitable, and inhabited historical center.

Cuenca’s plan is divided into four aspects: an urban acupuncture strategy, which proposes small / medium-scale interventions to recover areas with potential; a development of a network of active courtyards, by transforming the typical patios of Cuenca in catalysts capable of generating new synergies, connections, and interactions between residents, visitors and inhabitants; a guide to the historic center re-design, which defines the main lines for the design of the public space; a process of socialization, to define the “acopuntura” and the active patios network strategies. The intervention strategy in the square “Mary Corilè” in conjunction with the creation of “La casa en el árbol” is part of the active patios network strategy. This square is an unused and degraded space, perceived by the residents as an unpleasant and dangerous place.

The square "Mary Corilè"

The square “Mary Corilè”

Among the several interventions proposed, such as the re-furnishing of the square, traffic closure, and the design of activities in collaboration with the municipality, there’s also the creation of “La casa en el árbol“, a space included in the existing trees of the square where educational activities in relation to the theme of the environment can be carried out. “La casa en el árbol” is set up as a space to get in contact and be familiar with the nature, built in harmony with the surroundings. Inside there are several “environmental” classrooms in which one can study natural resources such as sun, wind, and water. More specifically, one can study: a system of photovoltaic panels that generate the energy needed for the lights, rainwater harvesting structures, and urban gardens as environmental and ecological experiences for schools and kindergartens. It is, ultimately, an open classroom in which a new form of pedagogy built on the respect for the environment is proposed, in order to increase awareness of the natural resources and of their use, as well as increase awareness of existing technologies.


In the case of Asunción we proposed a strategic plan with ten actions in order to promote a connection between the several parts of the city through the development of spaces, named “corridors“, and of individual buildings, named “urban catalysts“, which might act as drivers of change and benchmarks within the city. The corridors are divided into three types: those “green“, which introduce a new green infrastructure in specific parts of the existing roads; those “civic“, which consist of a new network of public spaces along the roads in order to connect the most important historic and government buildings; those “dynamic“, aimed at creating active urban environments and encourage economic and cultural activities.

Configuration of a charateristic dynamic corridor

Configuration of a charateristic dynamic corridor

Among the actions of Asunción strategic masterplan one concerns the economic and landscaping regeneration of the “Green Active Coast”. Due to its topography, this area is subject to cyclical floods because of the rising water level of the Paraguay River. That forces the inhabitants of the informal settlements who live there to move temporally. While fully respecting the identity of the river and of the existing topography, we have proposed the creation of a green lung with a large sports area in continuity with the Bicentennial Park. We also promoted the integration of the informal settlements both within the urban fabric and in the areas of new urban expansion.

The Encarnación masterplan incorporates within its own name the concept of “sustainability”, since it is composed of the “Plan of Sustainable Development” and of the “Plan of Urban and Territorial Organization”. The “Plan of Sustainable Development” will establish the standards and mechanisms for the growth and for the future development of the city according to the criteria of sustainability. The “Plan of Urban and Territorial Organization” aims at directing the use and the occupation of the territory in the urban and rural areas of the municipality. Officially, the city will face in the next twenty-four years an increase of the population amounted to 62,000 people, for whom it will be necessary to provide a massive increase in housing. The model we proposed to face this need refers to the sustainable principle of “the compact city.” Through the identification of a physical border for the city’s urban growth, we have protected the rural areas from new settlements. Moreover, we encouraged, through private and municipal initiatives, the densification of areas already developed, by filling the vacant urban lots and expanding pre-existing single-family homes.

Example of urban densification

Example of urban densification


The new interventions follow the principles of the bioclimatic architecture: large overhanging roofs and vegetation as protections from the hot summer sunlight, the use of wind to moderate the hot and humid climate of Encarnación, the reuse of rainwater, and the increase of the vegetation to absorb CO2 emissions.

TECHNOLOGY

In all four projects, technology represented an important collaborative tool to promote our work and to enable everyone to be constantly updated on ongoing progress, but also as a support for the participatory process, so that the involvement of the citizens would not be exhausted with the end of the activities organized, but could continue to map needs, issues, concerns and initiatives for those interested.

For this reason we have developed a platform, called Local-in (formerly What if ..?), which has been adapted to each project according to their personality and to the peculiarities of each participatory process, while maintaining a common format. Local-in is a free and accessible to everyone application of collective mapping. In it, registered users can add messages, photos and geolocalised links, sorting them into categories and labels. It’s easily installable and customizable, in perfect harmony with the spirit of the projects themselves, and it can be found for each project under the name “AsuMAP” for Asunción, with the name “Encarnación Más” for Encarnación, as “Cuenca RED” for Cuenca and with the name “Centro Histórico Abierto” for Distrito Central.



Comment: (1)

Open Shore Project for West Palm Beach | #1 Strategy to Trigger The Change

Category: ⚐ EN+competitions+ecosistema urbano+sustainability+urban social design+urbanism+work in progress

As we announced a few months ago in our previous post,  our project Open Shore is the winning proposal of Shore to Core international competition.

Open Shore is a complex project that addresses many different topics in an effort of providing solutions to several challenges that the city of West Palm Beach shares with many other cities. For this reason, we decided to present more in detail our project in a series of 3 posts dedicated to the three main points of the proposal: #1, Strategy to trigger the Change; #2, Waterfront: celebrating unexpected public space; #3, Banyan Hub: a city into a building.

Before going into detail of our proposal, it would be useful to introduce the context of the city of West Palm Beach.

As reported in the Shore to Core Competition Website, West Palm Beach is a young city that is growing quickly. Many associate this region with a large retirement community, but there is also a growing population of people in their 20s and 30s, as well as large Black and Hispanic populations. The city’s downtown and 10-mile waterfront present an opportunity to develop new amenities that reflect the city’s emerging populations, and design is a crucial tool for tackling these evolving needs.

The design competition asks: How can we reimagine our downtowns to make them more engaging and vibrant? How can cities collect information that informs future adaptation and growth?  How can we facilitate social interaction among diverse groups? How can the built environment improve residents’ physical health,  mental health, and social capital?

Today we present the first post of the series, starting the narration of this exciting experience. This first chapter introduces the previous analysis and the general strategies that informed the design of the project areas.

continue reading

Comment: (1)

Ecosistema Urbano is working with the European Commission in EU GPP Criteria for Public Space Maintenance

Category: ⚐ EN+ecosistema urbano+news+research+sustainability+work in progress

We are glad to announce our recent collaboration with the Joint Research Center of the European Commission in Seville for a research project focused on the topic of maintenance of public space. The project aims to define the EU Green Public Procurement (GPP) Criteria for Public Space Maintenance.

But.. what is exactly EU GPP? Here there is a short description coming directly from the European Commission official webpage.

Green Public Procurement (GPP) is defined in the Communication (COM (2008) 400) “Public procurement for a better environment” as “a process whereby public authorities seek to procure goods, services and works with a reduced environmental impact throughout their life cycle when compared to goods, services and works with the same primary function that would otherwise be procured.”  GPP is a voluntary instrument, which means that Member States and public authorities can determine the extent to which they implement it.

Public authorities are major consumers in Europe: they spend approximately 1.8 trillion euro annually, representing around 14 % of the EU’s gross domestic product. By using their purchasing power to choose goods and services with lower impacts on the environment, they can make an important contribution to sustainable consumption and production.

Green purchasing is also about influencing the market. By promoting and using GPP, public authorities can provide industry with real incentives for developing green technologies and products. In some sectors, public purchasers command a significant share of the market (e.g. public transport and construction, health services and education) and so their decisions have considerable impact. EU GPP is an important tool as it can contribute to the stimulation of the market for environmentally-friendly goods, works and services and to contribute to the development of a more resource-efficient economy in the EU. The Commission has developed EU GPP criteria for around 20 different product groups.

Here the complete list of 20 product groups considered for EU GPP Criteria, and as you may notice the range is really wide, from Office Building Design, Construction and Management, to Transport or Computer and monitors, to mention a few.

We are now working on the first phase of the project for the development of the EU GPP Criteria for Public Space Maintenance. One of the very first document produced is a Stakeholder Questionnaire aiming to define the scope. The questionnaire has been sent to several identified stakeholders from the supply side (Providers of maintenance services, equipment, public furniture, etc), demand side (public and non-public procurers) and other stakeholders, such as national or local policy makers, environmental organizations, urban planners and designers, citizens organizations, etc.

The scoping questionnaire is available at the following link for all interested parties to contribute:

http://susproc.jrc.ec.europa.eu/Public_space_maintenance/documents.html

If you are interested in participating please express your opinion through the questionnaire, and submit it to the email address

JRC-PUBLIC-SPACE-MAINTENANCE@ec.europa.eu before the 17th March 2017.

Further questions or registration by sending an email to JRC-PUBLIC-SPACE-MAINTENANCE@ec.europa.eu



Comment: (1)

City Splash! for Copa Cagrana Neue | ecosistema urbano + transform.city proposal for Vienna

Category: ⚐ EN+architecture+city+ecosistema urbano+landscape+news+sustainability+technologies+urbanism



Last November we were selected, in collaboration with Transform.city, to participate in the Neue Copa Cagrana International shortlisted competition in Vienna (Austria). The scope of the competition was the urban revitalization and definition of the Master Plan in the area Neue Copa Cagrana defining an urban proposal and the relationship of this part of the city with the river.
We were selected along with other 8 teams, including renowned firms such as Dominique Perrault, AZPML, or West 8.

The context: Donau City, Vienna

The study area is located next to Donau City, on the left bank of the new Danube Canal, Neue Donau, passing through the city of Vienna. It is a neighborhood of mainly tertiary character with office buildings of great height, developed in the last 20 years, including the Vienna International Centre.

Copa Cagrana – the intervention area, between the Danube and the new urban area with the D. Perrault’s tower

Despite the good connection with the city center, the large number of buildings and the excellent existing natural qualities, the area is almost deserted during day and night. This is mainly due to the lack of variety of uses, commercial facilities and recreational areas.
The proposal develops a series of strategies to revitalize an area that already has the optimal conditions to become a landmark for the city of Vienna:

FOUR OBJECTIVES

1 – Increase density and urban mixture

The proposal aims to incorporate urban, commercial and leisure life at a time when Vienna is starting to look for other forms of identity for the river area. It is important to bring new residents to help to create urban activity throughout day and night, summer and winter seasons by permanent and temporary uses. The mixed-use and residential functions in the first row, including the urban boulevard, have the potential to complete and complement the existing urban fabric and establish, for the first time, the necessary connections to make Donau City a functioning and exciting neighbourhood.

Activity diagram for the different seasons

The project proposes a high density urban prosthesis, combining housing, office, commercial and public space, in order to create an active urban spot connected to the surrounding, improving its identity and multiplying the possibilities of use.
The proposal seeks to make Donau City easier to be understood and perceived, with a clear connection to Danube river and its waterfront. Therefore, the proposal is the missing link to the completion of the Donaustadt and is, at the same time, the necessary catalyst to enable the urban regeneration in the area.

2 – Create new urban spots

Copa Cagrana will be an exciting new urban spot in Wien, which is perfectly connected to the city network thanks to the transport connectivity and subway line. Through the physical proximity with existing Donau City, Donau Insel and surrounding neighborhoods, the area will increase popularity and will offer more attractions to the users.
The newly created waterfront will be an urban catalyser with a variety of urban functions, with uses according to the seasons and day and night time:
The FILTER ZONE is a more quiet area free of commercial activities.
The TEMPORARY ZONE changes according the different seasons, with beach bars in the summer, pop-up restaurants, terraces and platforms, etc.
The WATERFRONT is an enjoyable walkable strip with piers and exciting water activities for summer and winter.

The FILTER ZONE

3 – Renaturing (urban+nature landscape)

A new urban and natural environment intrinsically connected with surrounding nature.
It will be the connecting environment between Donauinsel and Donau Park but also extending its limits over the water landscape of Neue Donau to create a vibrant and diverse waterscape.



Masterplan 1:1000

4 – Digital Identity – web app strategy

It is important to create the communication channels in order to advertise and share information about the ongoing activities and as a way to share potential ideas to be implemented. This web APP is thought to work as a social network that provides information for the citizens of Copa Cagrana on what kind of activities they can do on this renewed urban area.
Users will be able to register and create a user profile, with this, they will have the opportunity of proposing activities that will make use of the beautiful surroundings and installations of this urban space. The commercial sector will also have their own space. They will have the possibility of creating a profile which will allow them to publicize their products and business, as well as invite and inform citizens about special deals, offers, events and other celebrations.



FIVE NEW URBAN ZONES

Cross Section

Seeking to achieve these four objectives, the proposal creates 5 zones acting together and related to each other:

Zone C+: Infiltration city

The energy of city life will splash towards Donau City and the urban plinth will extend its limits to bring activity and reconfigure the public spaces around the corporative and residential buildings. These urban tentacles will extend urban plinth limits with linear and small scale pavilions, pop-up stores and cafes, etc. reconnecting and renewing the pedestrian pathways of the Donau city.

Elevation

Zone C: Social life city

Zone C proposal is the most powerful urban energy boost, as it provides a large amount of overlapped new programs and public spaces easily accessible at different levels.
Areas:
Urban plinth: fragmented construction from 1 to 4 stories high, multiple programs with predominance of commercial spaces overlapped with public spaces at different levels.
Vertical ecosystems: housing towers with a myriad of different typologies to create a diverse neighbourhood. The housing units help to create a dense neighbourhood with urban life throughout the day.
Urban bridge: On the tenth floor, same level as the top terrace of the existing linear building of social housing, a bridge is creating connections between semi public spaces, with diverse programs within the vertical ecosystems.
Public peaks: the top floor of the different towers is also part of the network of semi public spaces within the vertical ecosystems. These spaces can hold multiple programs and part of their success will be the privileged point of view of the city (terraces, cafes, common spaces,… )

Zone B: nature city

This is a zone where nature is predominant and the urban plinth is melting its limits with the landscape. At the same time, the natural character of this area helps to make the transition between the bigger, urban scale of zone C and both the lower scale of zone B and the waterscape towards Donauinsel, combining natural areas with paths for soft mobility.

Different cross sections in zones A and B

Zone A: Leisure city

Leisure cityscape to allow the transition between the formal city and the vibrant and ever changing new waterscape of zone C+. It will hold multiple permanent uses but also temporary programs and seasonal activities. There are multiple temporary and permanent uses in small buildings with similar language, as well as a new riverside walk that will extend to create a comfortable linear space. The relationship with water and the elevation difference will be resolved with a wooden platform that will act as an urban sofa to relax and enjoy the presence and proximity of the river.

Zone A+: Water city

Vibrant and ever changing waterscape in continuous evolution. It will extend the activities of the new urban spot towards the water.

Masterplan 1:2000

+ water pier: permanent pier, water thematic. Light structure with indoor and outdoor spaces to allow the creation of different bathing experiences. The use will change seasonally, during the winter, outdoor and indoor climatized pools will allow the user to be in connection with the surrounding natural landscape while having a pleasant bathing experience.

The water pier for summer activities

+ ice pier: permanent pier, ice and climbing sports oriented. Light structure with a strong seasonal connection. During the winter, part of the structure will be a huge frozen and faceted vertical surface to practice ice climbing, while the lower platform will host different ice skating outdoor rinks to practice in connection with the water and natural landscape. During the summer the ice surface is transformed into a huge waterfall falling from the upper level into the river.

ice pier_con nieve

The ice pier for winter climbing

+The urban archipelago: big modular and floating ever changing extension of the waterfront. The different seasons and uses will dramatically transform its configuration. This mutant landscape is built with modular floating platforms/barges that can be combined to create larger flat surfaces if necessary. These platforms can be connected to the limit line of the waterfront to extend its surface.

If you want to know more about the proposals you can download the competition panels here:
Panel 1   Panel 2   Panel 3   Panel 4

Comments: (0)

ecosistema urbano at ISU talks #3: Ruralism | international conference in Braunschweig, Germany

Category: ⚐ EN+landscape+news+sustainability+urbanism

Snoehetta_Petter-Dass-Museum_04

Next November 18th, Belinda Tato will be keynote speaker at the International Conference, ISU Talks #03: Ruralism organised by the Institute for Sustainable Urbanism. Other speakers include Snøhetta, OMA/AMO, etc…

The institute is located in Braunschweig, Germany and according to their own definition is part think-tank, part design laboratory, committed to promoting research and scholarship on sustainable urbanism in an international and interdisciplinary setting.

Since October 2012, ISU is lead by Prof. Dr. Vanessa Miriam Carlow, within TU Braunschweig’s Department of Architecture, Engineering, and Environmental Sciences. ISU has worked with partners in Africa, Asia, South America, USA, and all over Europe. ISU has four themes under which its teaching and research projects fall: Space as Resource, City in Society, Impossible Sites, and Urban-Rural Relations.

Here is a brief introduction to the Conference:

In the current city-centred discourse, rural spaces are often dismissed as declining or stagnating. However, rural spaces also play a critical role in sustainable development, as an inextricably linked counterpart and complement to the growing city, as extraction sites, natural reservoirs, providing for ecosystem services or leisure spaces.
The city and the countryside are evermore increasingly mutually reliant. A closer look at the countryside unveils a set of dynamics overlaying and changing rural space, beyond trends of depopulation and shutdown of public facilities. The once remote and quiet countryside is now traversed by global and regional flows of people, goods, waste, energy and information, interrelating it with the larger urban system, even bringing it to the frontlines of regional transformation and sustainability.

The conference proposes the following questions:
– How can the contemporary rural be conceived of and described?
– What new concepts for rural living currently exist?
– How are urbanisation and ruralisation processes connected?
– Can impulses for the design of urban space be drawn from the imagined and practiced connections between the urban and the rural?
– How can we formulate a (new) vision for ‘ruralism’?

More info

Comments: (0)

Archiprix International – ecosistema urbano takes part in the Awards ceremony

Category: ⚐ EN+architecture+creativity+ecosistema urbano+events+urban social design+urbanism

archiprix_madrid2015-960x576

In the past two weeks, Madrid has been the capital of the most innovative and vibrant ideas coming from the academic environment worldwide. In fact, Madrid was chosen for the 2015 edition of Archiprix International, a biennial event that involves all schools worldwide in Architecture, Urban Design and Landscape Architecture to select their best graduation project.

The event consisted of two sections:

Towards a middle-out urbanism

All participants were invited to participate in the Archiprix International workshop, that took place at ETSAM. These best graduates from around the world form a unique group of young talented designers. From surgical interventions to visionary statements: the best graduates from all over the world were invited to Madrid and challenged to develop plans and design proposals in a multidirectional approach to the city. The workshop was conducted by DPA-ETSAM and Los Bandidos AG and tasks were led by emerging local practices.

facts

We were invited to be part of the jury to evaluate the projects resulted from the 7-day workshops and to present our overview and conclusions about this work during the final Award Ceremony that took place at Cine Callao on Friday May 8th.

16891768904_d76e02e80e_o

In our talk we reflected on the topics that emerged throughout the different proposals and groups. In addition to this, we presented our vision of how designers and architects need to equipe themselves to be able to deal with contemporary urban issues, what we understand is the new designer’s role and the importance of incorporating new tools in architecture.

16894228313_1e2b89d780_o

Belinda Tato talking about the variety of topics related to architecture

17326816098_4c8c7693d6_o

Jose Luis Vallejo explaining the concept of “one-man band” in architecture

17512386842_5025feb3be_o

Iñigo Cornago talking about the importance of bottom up actions

gif-4-projects

Four projects from the Archiprix workshops

Archiprix International Madrid 2015

Extensive presentation of the world’s best graduation projects, selected by 351 schools from 87 countries.

map

Map of participants in Archiprix 2015

The jury comprised Eduardo Arroyo, Luis Fernández-Galiano, architect and editor of Arquitectura Viva, Anupama Kundoo, architect with her own practice in Auroville (India) since 1990; Zhenyu Li; and French landscape architect Catherine Mosbach. The jury reviewed all submitted entries at the ETSAM | UPM – Escuela Técnica Superior de Arquitectura de Madrid, Universidad Politécnica de Madrid, the co-organizer of the eighth edition of Archiprix International. The jury nominated 21 projects for the Hunter Douglas Awards and selected 7 winners out of these nominees.

winners

Winners of Archiprix International

Here you can have a look at all the selected projects and the seven winning projects.

The 9th edition of Archiprix International -2017- will be held in Ahmedabad, India.

It has been a great pleasure to be part of this inspiring event and getting a chance to see and hear how the most talented architects are thinking throughout the world.

We wish all of them the best luck for their brand new careers!

More info about Archiprix

Comments: (2)

Ecosistema Urbano, first prize in the Voronezh Sea Closed Competition

Category: ⚐ EN+competitions+ecosistema urbano+news

Aerial view of the "Leisure Island"

Aerial view of the “Leisure Island”, one of the proposals

The Department of Natural Resources and Ecology of the Voronezh region decided recently to organize a closed competition in order to develop a strategy for the future of the Voronezh Sea, a currently contaminated reservoir. The aim was to gather ideas on the use of the reservoir so it can be more attractive for the population and be a resource for the development of the city once the water is clean.

Today we are pleased to announce that our proposal has been awarded the first prize!

Click on the image to see some cool panoramas of the Voronezh Sea!

Click on the image to see some cool panoramas of the Voronezh Sea!

The proposal developed by Ecosistema Urbano after being selected for the second round of the competition works at different levels, addressing both the diverse sources of contamination and the potential uses of the existing reservoir. Our vision combines various solutions bringing new opportunities for leisure and activities for people to enjoy and experience the lake.

Our proposal

Addressing the different sources of pollution by providing customised solutions for each of them. These actions are framed as Phase 0. Among the actions we propose to place macrophytes on the surface of the water treatment plant tanks. This action can improve the performance of the Plant up to 40% and it is more efficient not only in the short term, but also in the long run as it reduces energy consumption and requires low maintenance.

Working with floating macrophytes which can absorb many different contaminants. They would be located in the shallowest areas of the lake to stop algae from blooming and emitting a specific smell that comes from the reservoir in summer.

Floating macrophytes in action

Floating macrophytes in action

Creation of bathing areas both in the urban and at the natural environment of the lake, incorporating the macrophytes as part of the water purification system.

A series of floating mobile cleaning infrastructures. These barges help to control water eutrophication as it is important to reduce the amount of phosphorus. They have tanks filled with alum for phosphor sedimentation at the bottom and incorporate various leisure programs and possibilities on the top, so they can be used in different areas of the city during the summer season. At the same time, these floating barges include sampling and analysing systems so that real time information about the water conditions and quality is made available for everyone through the web platforms and mobile app, specifically developed for this purpose.

Floating mobile cleaning infrastructures

Floating mobile cleaning infrastructures

Two areas are proposed to be developed through Public-Private Partnership. These new developments will help to shape a new identity for Voronezh and a new relationship of the city with the water.

The first is a mixed-use zone including housing, offices, retail, public and cultural buildings etc. This new development must be a pilot experience incorporating all the current sustainable technologies, as well as incorporating good practices in water management. Rainwater and surface water runoff is collected and purified through small ponds with floating macrophytes for being used afterwards for irrigation. Pump system for ponds and aeration fountains receive energy from micro wind turbines located on the shore.

New development of a mixed-use zones at the lakefront

New development of a mixed-use zones at the lakefront

As a second development opportunity, ecosistema urbano proposes turning the existing Pridachenskaya dam into a Leisure Island with different activities, becoming a new infrastructure for the city incorporating clean water areas available for swimming and bathing. The island also includes bicycle and jogging paths, boat station for water-sports, urban beach, gardens and parks, playgrounds and sport facilities.

Typologies of cleaning and activity-hosting infrastructures

Typologies of cleaning and activity-hosting infrastructures

Next you can see some more images of the proposal, showing how water treatment and environmental regeneration could work together with social reactivation of the reservoir along the day and through the seasons.

Swimming-pools

Leasure-Island-Day

Leasure-Island-Night

Eco-path

Related links (in Russian):

EU project ideas
Results of the competition
Voronezh news
